[0:06]Assalamu Alaikum Dosto. Dosto, aaj ki hamari jo video hai, ye hamari Deep Sea Controller 8610 MK2 ke upar hai.
[0:17]Ye Deep Sea Controller, isko synchronizing module bhi kaha jata hai aur load sharing module bhi kaha jata hai.
[0:25]Iske upar sabse pehle humen ye navigation keys mil jaati hain char adad. Ek, do, teen, char aur ek enter ka button mil jaata hai.
[0:38]Uske baad ye sath display aa jata hai. Uske baad hamare pas ye char indications aa jaati hain jinko warning indication kehte hain. Aur ye warning indication hum apni marzi ke sath, humne jo jis ka bhi alarm warning alarm lena hota hai, uske samne hum uska tag yahan pe likh dete hain uske sath.
[0:55]Aur uske baad hamare pas ye off ka button aa jata hai. Iske do purpose hote hain. Ek to ye module ko reset karne ke liye istemal hota hai aur dusra generator ko off karne ke liye, manually off karne ke liye.
[1:10]Uske baad ye hamare pas manual ka button aa jata hai. Uske baad hamare pas auto ka button aa jata hai. Auto pe agar humne isko start karna hai to hum ye wala button dabayenge aur ye indication iske sath on ho jayegi.
[1:22]Aur uske baad agar manual karna hai to ye button dabayenge aur ye indication hogi uske baad humen start ke liye ye wala button on karna padega. Aur agar humne synchronizing jab ye start ho jayega to ye indication is jagah pe on ho jayegi load ki. Aur jab humne load share karna hoga to hum ye button press karenge aur hamara breaker lag jayega.
[1:47]Ji to dosto, ab hum baat kar lete hain iski wiring ki aur iske baki jo bhi functions hote hain un sab ki.
[1:54]Sabse pehle, iske sections hote hain jaise number ek se 14 tak ek section hai. Uske baad 15 se 22 tak dusra section hai aur uske baad 23 se leke 39 number tak teesra section hai. Isi tarah se ye chautha section, ye panchwan, chatha, satwan, aathwan aur nauwan. Iske total nau sections hote hain.
[2:23]Deep Sea Module 8610 ke. Ab iski hum wiring ki baat kar lete hain. Sabse pehle section one pe jaate hain. Section one pe jaisa ki aapko nazar aa raha hai, yahan pe battery ka sign show ho raha hai aur one number pe negative aur two number pe positive ki wire lagayi jati hai jo hamari.
[2:43]Aur uske baad number teen ke upar ye hamara emergency stop ka sign hai. Emergency stop ka terminal ye number teen pe diya gaya hai aur ismein jo wire aati hai, ye hamare emergency push button jo ye laga hua hai. Iske through normally closed se guzarte hue yahan pe aati hai. Aur ye hamari.
[3:02]Uske baad hum baat kar lete hain number four aur number five ki. Number four aur number five ye wala jo section hai, ye positive sign aur uske sath niche arrow. Iska matlab hai ki ye hamare paas positive outputs hain.
[3:14]Positive outputs number four ko hum istemal karte hain. Iske do maqsad hote hain number four ke liye. Fuel aur ECU power up ke liye istemal karte hain. ECU matlab electronic control unit. Uske power up ke liye aur fuel ke liye number four ko istemal karte hain.
[3:30]Uske baad hamare paas number five aa jata hai. Number five ko hum number five ke upar ye 305 hamari tar lagi hui hai.
[3:40]Isko hum istemal karte hain motor starter ke liye. Motor starter ke liye panch number aur jo char number ki wire hai, isko hum istemal karte hain fuel ke liye. Ye bahut ahem point hote hain.
[3:52]Uske baad number chhe pe jaate hain. D plus W/L. Is ye wala jo point hota hai, ye hamara DC alternator ka point hota hai jisko DC charger bhi bolte hain. Jaisa ki har engine ke andar ek DC charger hota hai jo battery ko jo battery ko charge karta hai, ye uski wire 306 ke upar aa ke lagti hai. Is five.
[4:16]Ji to dosto, ab hum baat kar lete hain is section ki, 7 to 14. Ye wala jo section hai, ab ab aap dekh rahe honge is ye wala sign aur ye wala sign ye dono same hain.
[4:30]Lekin ye wala jo block hai, isko dedicated kiya gaya hai fuel aur starter motor ke liye. Jabki ye wale jo points hote hain, isko inko bolte hain user configuration point. User configuration point ka se muraad ye hai ki ye 7 se 14 tak jo point hain, inko hum through ye wala jo port hai, yahan pe hum PC connect kar ke iske sath aur isko apni marzi ke sath positive output yahan se le sakte hain jo humen required hon.
[5:06]Theek hai dosto. Uske baad ye wala hamara section one complete ho jata hai. Uske baad hum baat kar lete hain second section ki.
[5:13]Second section ke andar sabse pehle hamara ye wala jo sign hai, ye ye show karta hai analog outputs ko. Analog outputs generator ke andar jaise temperature sensor hota hai, low fuel sensor hota hai, all pressure sensor hota hai. Ye jitni bhi hamari outputs hoti hain, ye analog outputs hoti hain. Kyunki ye apni apni value ko musalsal tabdeel kar rahi hoti hain.
[5:37]Isi tarah se ye 15 number ke upar ground ki wire aa ke lagegi aur further aap aapki jitne bhi sensor hain, unki wires yahan pe aa ke connect hongi.
[5:45]Can ka matlab common area network. Kuch ECU generators hote hain jo common area network configuration required hoti hai jinko.
[5:57]Uski jo wires hain, wo yahan pe aa ke connect hoti hain. H pe high, L pe low. SCR pe shielded wire aa ke aapki connect hoti hai.
[6:13]Uske baad next third one jo section hai, uske andar ek fly wheel hai uske upar sensor laga hua hai.
[6:20]Ye wala jo sign hota hai, is sensor ko MPU bolte hain. MPU ka matlab magnetic pickup unit. Agar hamara generator electronic nahi hai to uski jo wires aa ke lagengi wo yahan pe aa ke lagengi. Agar hamara generator electronic control hai to uski jo wires hain wo ECU electronic control unit mein aa ke lagti hain.
[7:10]ECU ke baad hamara jo agla block aata hai ye jismein ye do sign bane hote hain, ek upar aur ek niche. Isko deep sea net kehte hain. Agar aap ek se zaid module deep sea module lagana chahte hain to module ki jo communication hogi wo deep sea net ke zariye hoti hai jo ye wale point hain.
[7:41]Uske baad hamare pas ye wala sign aa uske baad hamara jo block hai wo ye wala aa jata hai jismein jis mein ek arrow upar aur ek arrow niche hota hai. Isko Deep Sea net kehte hain. Deep Sea net iska maqsad jo hota hai wo hota hai ki in case humen ek se zaid module ki zarurat pad jati hai bajah jo uski wajah jo hamare paas ye jo analog outputs hain iski agar hamare paas analog outputs zaid hon aur yahan pe point kam ho to uske liye agar humne module extra lagana hai to uski jo module ki apas mein jo communication hoti hai wo through Deep Sea net hoti hai.
[8:18]Next one jo hamara point aa jata hai wo MSC aa jata hai. MSC ka matlab multi signal communication. Multi signal communication ye wala jo point hai ye bahut ahem point hota hai synchronizing ke andar. Kyunki agar humne ek se zaid generator humne apas mein sync karne hain. Kyunki jo hamara 8610 ye wala jo module hai ye ek waqt mein 49 generator ko apas mein sync kar sakta hai. To ye wala jo generator hoga first one us pe aur jo last one 10th jo generator hoga, uske controller pe humen MSC pe ek 120 ohm ki resistance install karna padegi first one aur last one.
[9:32]Aur jo inmein connection hoga ye through daisy chain ek se dusra, dusre se teesra, parallel mein is tarah se ye chalta jayega. Jo ismein communication hoga. Communication jo module mein hoti hai wo inke apas mein frequency matching aur voltage matching. Ye jo jo bhi inmein apas mein communication hogi wo through MSC hogi.
[9:57]Uske baad next one jo GOB. GOB matlab governor. Ye wale jo governor aur AVR, ye wale jo do point hai, ye sirf humen is module mein milenge. Uski wajah kya hai ki ye wale jo module hai ye synchronizing ya load sharing module kehlata hai.
[10:14]To aapko pata hai ki jab hum kisi generator ko sync karte hain to uske liye humen frequency match karna hota hai, voltage match karna hota hai aur phase sequence match karna hota hai. To uske liye governor speed ko control karta hai jisse hamari frequency control hoti hai.
[10:31]Governor ki jo wire hogi wo yahan pe aa ke connect hogi. B aur A 35 aur 36 ke upar. Aur dosto ye wali jo hamari hoti hain, ye wale jo points hote hain, ye analog outputs hote hain jo humen plus minus 10 volt DC humen provide karte hain jisse hum is governor hum speed aur AVR voltage ko ya excitation ko control karta hai.
[11:06]Uske baad next jo hamara block aa jata hai iske andar 40 aur 41, 42 aur 43. Ye wale jo parts hain, inko voltage free contacts kaha jata hai. Voltage free contacts matlab jis tarah ek relay ke andar hamare contacts hote hain ke normally open ya normally close.
[11:28]Ye uske baad V1. V1 44 se 47 tak ye wali jo hai, ye wali jo point hai, ye hamare generator ke voltage hote hain. Uske baad V2. V2 hamare bus voltage hote hain.
[11:47]Bus voltage jo hamare outputs pe chal rahe hote hain aur V1 pe jo hamari incoming aa rahi hoti hai. Ab V1 aur V2 kyunki hum aapko pata hai ki jab humne synchronization karni hai to hamare voltage same hone chahiye. To jo first jo bus ke voltage honge uske mutabiq ye apni voltage through AVR control karne ke baad ye breaker ko on karwayega.
[12:16]Uske baad hamare paas next one jo block aa jata hai, ye hamara CTs ka block hota hai. S1, S1, S1, ye wali jo red, yellow, blue aur uske baad hamare paas ye grounding aa jati hai. Ye wali jo hamari CTs ye wali jo jo point hai ye hamara CT ka point hota hai. Yahan pe hamari CT aa ke connect ho jayegi.
[12:41]CT ke do point hote hain S1 aur S2. S2 jo common ho jata hai aur S1 ko hum further alag alag red, yellow, blue hum apni wire le ke connect kar lete hain.
[12:53]Uske baad hamare pas ye wala jo block aa jata hai ye hamare pas digital inputs ka block hota hai. Digital inputs binary inputs hoti hain, on ya off, zero ya one. Matlab ke hamara pressure switch on hai ya off hai. Ye iske ilawa remote start ka signal aa jata hai ismein. Feedback ka signal aa jata hai. Oil pressure switch ka signal aa jata hai. Water pump water temperature ka signal aa jata hai.
[13:18]Kehne ka matlab ye hai ke ye wale jo points hain ye readings show nahi karenge. Ye just jo hamara controller hai usko just ye ensure hoga ke on ya off. Temperature temperature switch on aur off. Breaker on aur off. Ye digital inputs hain.
[13:41]Uske baad hamara jo next section aa jata hai wo ye wala aa jata hai. Ismein ye wali jo port hai ye hamari ethernet ki port hoti hai. Jahan pe ethernet ki cable lagegi. Uske baad hamare paas ye wali jo port hai ye USB port aa jati hai. Ye USB port ka maqsad is controller ke event log mein 250 alarm save ho sakte hain.
[14:04]Agar humen usse zaid iski agar humne 250 se zaid alarm ke liye iska record rakhna ho to uske liye hum ek external USB ismein install karenge aur install karne ke baad jab humen jab humen data chahiye hoga hum nikal ke PC ke sath connect kar ke iska sara data nikal sakte hain.
[14:24]Uske baad ye hamare paas A type top port aa jati hai. Ye configuration port hai. Isko configuration port bhi kehte hain. Ye ismein module ke andar software install karne ke liye istemal hoti hai.
[14:37]Uske baad hamara ye wala section aa jata hai, last section. Is section ke andar hamare paas ye communication ports aa jati hain. Communication ports jis tarah se ye ethernet ki port thi isi tarah se ye bhi communication customer communication for SCADA for BMS system ke liye jo signals hote hain wo yahan se receive kiye jate hain.
[15:01]Uske baad hamare paas iski supply ka aa jata hai. Supply jo hai iski jo humne battery ko deni hai wo 8 se 35 volt 1 ampere maximum honi chahiye. Uske baad DC output T4 DC DC output 24 volt 15 ampere 4 and 5.
[15:24]T4 se T4 ka murad hai terminal 4 aur terminal 5. Ab ye terminal 4 aur terminal 5 hai ye 15 ampere pe operate hota hai. Jabki jo hamara terminal 7 se terminal 14 hai ye 2 ampere rating hai iski. Isliye jo hum jo T4 aur T5 ko hum fuel aur starter motor ke liye istemal karte hain.
[15:53]Uske baad DC inputs aa jati hain. DC inputs maximum 30 volt tak hum isko de sakte hain. Uske baad volt free point, volt free point 40 aur 41, 42, 43. Ye wale jo points hain ye 250 volt AC 8 ampere tak ho ja inki rating hoti hai.
[16:15]Uske baad AC voltage inputs. AC voltage input ye wali jo hum isko input de rahe hain ye 600 volt tak three phase mein hum isko de sakte hain. Input jo current hai jo cities ka current hai ye 5 ampere tak hum isko de sakte hain. Uske baad charge alternator jo humne D D W L 6 number point tha.
[16:34]6 number point charge alternator ye 30 volt DC 2.5 watt maximum provide karega. Uske baad magnetic pickup unit. Ye wala jo unit tha 23, 24 aur 25. 70 volt RMS aur 10 kilohertz maximum.
[17:02]Ye iski rating hai. Uske baad analog outputs ye wali. Analog outputs 10 volt DC maximum lengi. Iske andar ye wali bhi aa jati hain aur governor aur AVR bhi aa jata hai. Common port aa jati hai maximum 5 volt aur governor aur AVR plus minus 10 volt DC.
[17:21]Ji to dosto, ye hai aaj ki video. Ummeed hai ye aapko iski information achhi lagi hogi. Agar ismein koi bhi question ho to aap comment section mein question kar sakte hain. Uska uska properly aapko guide kiya jayega.
