[0:00]Removal of an escape slide raft after inflation.
[0:11]Disconnect the pack assembly electrical supply. The quick disconnect connector is installed below the cable routing Velcro.
[0:23]Open the Girt flap. Open the lanyard Velcro and remove the survival kit attach loop from the telescopic end fitting of the Girt bar.
[0:40]Open the blue and the green Velcro and separate the survival kit lanyard and the Girt bar release strap. Remove the Girt bar release strap from the Girt bar release lever. Pull the mooring line from the Girt pocket and support the escape slide raft with the mooring line. Pull the release handle and release the mooring line slowly and let the Girt lace up joints and the Girt assembly release from the Girt bar. Carefully lower the escape slide raft to the ground.
[1:29]Make sure that you do not damage the reservoir when you lower the slide raft to the ground. Hold the Girt bar and push in the Girt bar release lever by hand. Remove the Girt bar from the floor attach fittings. Remove the mooring line loop end from the Girt bar and keep the Girt bar with the aircraft. Lift the empty pack assembly soft cover clear of the passenger crew door and close the door.
[2:05]Remove the pack assembly decorative cover and keep it with the aircraft. Loosen the link nuts and remove and retain the attached link and the pull handle from the stud assembly. Remove the stud assemblies with the Allen key from the door attach anchor nuts.
[2:34]Move the packboard inboard on its supports and hold it. Disconnect the pack assembly connector from the electrical connector installed on the passenger crew door. Remove the packboard from the passenger crew door supports. Service the door damper and emergency operation cylinder.
